1. Adopting the special slewing support, easy operation, stable performance and large torque.
2. The shear uses imported HARDOX400 sheet material, with high strength and large shear force.
3. The blade uses the imported material and has long service life.
4. The clamping arms fixed the dismantled vehicle in three directions to facilitate the dismantling of the shear.
5. The shear with clamping arm can quickly disassemble all kinds of scrapped vehicles.
For more information, please e-mail or call us.
Model | Unit | JX-C08 |
Dead-weight | kg | 1900 |
Max Opening | mm | 630 |
Length | mm | 2475 |
Width | mm | 760 |
Rotation Mode | 360°Hydraulic | |
Pressure | Bar | 320 |
Root Shear Force | ton | 150 |
Middle Shear Force | ton | 106 |
Fore-end Clamping Force | ton | 56 |
Suitable Excavator | ton | 18-26 |
